Moro PM200 678 CFM Liquid Cooled Pump

Moro PM200 678 CFM Liquid Cooled Pump

Moro liquid cooled vacuum pumps are recommended for heavy duty continuous use applications. Some models have a unique liquid cooling system for the rotor, maintaining cooler temperatures inside the pump. Plus, the principle of positive displacement rotary vanes guarantees a high degree of vacuum, making Moro liquid cooled pumps ideal for industrial use.

CCW rotation: Part#: 6.211003220-1
CW rotation: Part#: 6.211003230-1

Recommended for heavy duty continuous use applications.

Product #: 6.211003220-2


Call for price 1-800-678-2459

Ships in 1 to 2 business days.

FEATURES

  • Sealed bearings - no grease points
  • Direct feed, sealed oiling system
  • High performance, Kevlar vanes with visual inspection ports in casing
  • High quality Viton oil seals - longer life than traditional oil seals
  • Low rotating speed leads to longer pump life
  • Sealed or oiled bearings - no grease points
  • Direct feed, sealed oiling system
Specification Unit Value
Free air capacity cfm 678
Air capacity at 15" Hg/50% vacuum cfm 635
Max. Vacuum Hg (in.) 28
Max. Pressure psig 14.5
Power required at 15" of vacuum hp 43.5
Power required at max. pressure hp 40
Rotation speed rpm 1250
Oil tank capacity quart(us) 1.45
Oil consumption gal (US)/Hr 0.063
Sound pressure at 7 meters (23 ft) 60% vacuum dB 74
Hose in -
Flange in 4
Weight lbs 970
R.P.M. Free
Air Flow
Performance
@15" Hg.
Continuous
Vacuum
Suggested
Tank Size
1250 677 cfm 635 cfm 24" Hg 2000-6000 Gallons

*Recommended R.P.M.
